Product Description
Specification | Particulars |
Milling Cutter | 3mm~20mm 2、3、4 Blade (Adjustable inner groove angle) |
Drill Bit | 3mm~20mm 2 Blade（120°~145°） |
Ball Cutter | 3mm~20mm 2 Blade |
Round-nose Knife | 3mm~20mm2、3、4 Blade |
Chamfering Knife | 3mm~14mm 2 Blade（75°~120°） |
Applicable Materials | Tungsten steel, alloy, high-speed steel, ceramics, graphite |
Tool setting Device | Probe tip (with an accuracy of 0.001) |
Overall Dimensions | 1000mm*700mm*1950mm |
Net weight of equipment | 230KG |
Total Power | 3KW |
Speed of Grinding Wheel | 2500~3000 |
Knife Sharpening Efficiency | 1~2min per tube |
Grinding wheel specification | 125mm*10mm*32mm/125mm*10*32*43V |
Grinding wheel Lifetime | 800~1000 6mm milling cutter |
Cooling method | Coolant (oil / cutting fluid) |
Selective Assembly ONE | Internal pneumatic spindle / Custom 2mm milling cutter program |
Selective Assembly TWO | Select 5-6 flute end mills / round nose cutters 4 flute ball cutters / 3-4 flute chamfering cutters / unequal pitch flat milling cutters / round nose cutters 2-6 flutes |
FEATURES
1. It can automatically grind 2/3/4 edge hard alloy/high-speed steel and graphite cutting tools;
2. Switch tool models and specifications freely without switching screens;
3. More convenient operation,anyone can complete grinding within I minute;
4. PLC program control performance is more stable and accuracy is higher;
5. Add cooling devices and oil mist collectors to make the sharpening process cleaner;
6. The grinding milling cutter is divided into blade angle, front oblique angle, and rear oblique angle;
7. Fully endosed body, environmentally friendly and pollution-free. After grinding the milling cutter standard should be consistent with the new cutter, and the high precision of the blade should be within 0.0lmm.
APPLICATION
Suitable for grinding alloy cutting tools, high-speed steel cutting tools, graphite cutting tools, and other cutting tools.
Easy to operate Fully endosed body with built-in cooling device and oil mist collection device
Suitable for factories with muliple specifications and varieties of grinding, second-hand tool grinding work,and factories with high environmental requirements.
